Nikki 2 bbl - NK563A - GMH

This carby was fitted to the Holden Gemini, Jackaroo and Rodeo as well as a few other makes. When doing the float level setting, I generally only lean the top cover at 45 deg. so the float just rests on the needle without compressing the ball/pin and then set the float so the top surface of the float is parallel to the gasket surface of the cover.
